YillumaxTM Hazard Obstacle Warning Series Solid Checker Pre-coated type SHG1830 Series Reflective Sheeting could be different kinds of 10 years durable products with embedded high reflecting index micro spherical glass beads in a double color pre-coating layer, while it performs very well to return the incident lights overall.
The series reflective sheeting is just customized of different patterns depend on client’s request. We can supply different colors checkers with customized sizes. Different surface film, different direction of strips for this series provides you different choices (Like SHG1830 (-25) etc.). This cost-effective film performs well in many applications.
Quick view
Performance: Match value of the coefficient of retro-reflection values of ASTM D4956 Type III 和 EN-12899 RA2 or See download Spec sheet for complete photometric performance list of each grade.
Durability: 10 Years Durability Life Vertical Exposure only.
Face: Acrylic Retro-reflective Film with Retro-reflectivity element.
Colors: customized
Adhesive: Permanent Pressure Sensitive white glue.
Liner: Single PE and Double sides silicone Coated Kraft release paper or Polymeric Film.
Application Surface: New PVC Curtains or Pre-cleaned hard surface (Wood and plastic boards are not recommended).
Width: 5cm, 10cm, 20cm, 1.22m..
Length: 45.7m, 91.4m.
Further Information
For more technical information such as adhesion, applications, storage etc. Please download the YillumaxTM each grade product spec sheet. The YillumaxTM application manual provides more Information on product usage and is available as a download. Or inquire more details from us directly.
